ClarkDietrich DRC6 Drift Rail Clip - 6 in., 12 ga

DRC6 (12ga) is a 6" Drift Rail clip in 97mil (12ga) steel, the moving half of the two-piece Drift Rail system. The clip rotates into the C-shaped rail for installation, then takes 3" of vertical deflection on FastClip™ deflection screws.

Product Information

• Thickness: 97 mil (12 gauge), 0.1017 in. design thickness
• Clip size: 6"
• Vertical deflection: 3" (1-1/2" up, 1-1/2" down)
• Also pre-punched with 1/8" holes for a rigid stud attachment
• Used with the ClarkDietrich Drift Rail (DR97)
• FastClip™ deflection screws for stud attachment
• Yield strength: 50 ksi
• Coating: G90 (Z275) hot-dipped galvanized
• Meets or exceeds ASTM A653 and A1003
• Common applications: seismic drift and lateral movement at curtain wall framing, rigid or deflection stud connections

Packaging: Sold individually or by the bucket of 25.

Manufacturer: View the Drift Rail (DR97) and Clip (DRC) page on ClarkDietrich.com for full specifications, load tables, and submittal documents.
