ClarkDietrich PW60 PONY WALL HEAVY (12 GA) 60IN *DOES NOT CURRENTLY HAVE LOAD DATA*

*FREIGHT CHARGES APPLY IF LESS THAN 25 PCS ARE ORDERED* PARTIAL WALL FRAMING CONNECTION TO FLOOR

The ClarkDietrich Pony Wall is intended to support out-of-plane loading of cantilevered partial wall systems that are unsupported at the top track. Out-of-plane loads are transferred to the floor system through the base-plate, which is welded to the Pony Wall stud member. Product DimensionsPW60 = 59-5/8" tall with 3-3/8" wide x 8" long plate Material SpecificationsPlate Material: ASTM A36 1/2" thick hot rolled steelStud Material: Structural Grade 50 Type H (ST50H), 50ksi (340 MPa)12ga (97mil), 0.1017" Design thickness, 0.0966" Min. thicknessPackaging: IndividuallyASTM: A36, A653/A653M, A1003

Product Data & Ordering Information

Click the below Product Code to view Tech Datasheet *DOES NOT CURRENTLY HAVE LOAD DATA* Product code Overall Height Packaging PW60 59-5/8" tall Individually 108 PCS PER SKID

Installation

Install the Pony Wall inside the track or directly to the floor structure. Anchor to the floor as designed by EOR. Attach the studs to both flanges of the Pony Wall. A minimum of 3-1/2" stud member can be used.
